Grounding Screw

/접지 나사

접지 나사

CORIGY SOLAR 접지 나사 및 접지 나사 앵커는 콘크리트 기초를 대체하는 데 사용되는 일종의 제품입니다. 현장 설치 작업을 최소화하고 현장 용접, 드릴링 또는 기타 현장 제조가 필요하지 않습니다. 지반말뚝을 고정한 후 사용할 수 있어 공사기간을 대폭 단축할 수 있다.
  • 브랜드:

    CORIGY SOLAR
  • Item NO.:

    GROUND SCREW
  • 지불:

    T/T, O/A, L/C, D/P
  • 제품의 원산지:

    CHINA
  • 선박 항구:

    XIAMEN
  • 리드 타임:

    Depends on project time and receipt time
  • 제품 상세 정보

상품명

접지 나사

재료

탄소강 Q235B

녹슬지 않는 처리

고급 용융 아연 도금

 파이프 직경

76mm~200mm

파이프 길이

500mm~3600mm

보증

10년 보증

지속

20년 이상

선적항

중국 샤먼항



1. 표준 접지 나사


사진

그것m 아니요.

아웃디아 (mm)

길이(mm)

두께


CP-76GSF-L-3.0T

76

L < 3600

3.0

CP-89GSF-L-3.0T

89

L < 3600

3.5

CP-76GSF-L-3.5T

76

L < 3600

3.0

CP-89GSF-L-3.5T

89

L < 3600

3.5


2. 큰 날 접지 나사

사진

그것m 아니요.

아웃디아 (mm)

길이(mm)

두께


CP-76GBF-L-3.0T

76

L < 3600

3.0

CP-89GBF-L-3.0T

89

L < 3600

3.5

CP-76GBF-L-3.5T

76

L < 3600

3.0

CP-89GBF-L-3.5T

89

L < 3600

3.5


3. 조정 가능한 접지 나사

사진

그것m 아니요.

아웃디아 (mm)

길이(mm)

두께


CP-76GT-L-3.0T

76

L < 3600

3.0

CP-89GT-L-3.0T

89

L < 3600

3.5

CP-76GT-L-3.5T

76

L < 3600

3.0

CP-89GT-L-3.5T

89

L < 3600

3.5
